By far the most popular of all straight-chromium stainless steels, Type 430 is the general-purpose alloy of the ferritic class. Referred to as “17 Chrome stainless,” this grade offers favorable resistance to mild atmospheric corrosion and oxidizing environments. Its resistance to corrosion can be enhanced and reflectivity improved with bright annealing.
430 stainless steel has good corrosion resistance, but in some specific environments, such as high-temperature chloride environments or during welding processes, intergranular corrosion may occur, leading to damage to the material's grain boundaries, reducing its corrosion resistance, and mechanical properties.
Product Name | 430 Stainless Steel Coil |
Type | Steel Coil |
Thickness | 2.5mm-10.0mm |
Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc. |
Width | 610mm-2000mm |
Standard | ASTM, AISI, JIS, GB, DIN, EN, etc. |
Surface | BA, 2B, NO.1, NO.4, 4K, HL, 8K, etc. |
Scope of Application | Widely used in high temperature and electrical industry, medical equipment construction, chemical, food industry, agriculture and ship parts, food and beverage packaging, Kitchen supplies, trains, airplanes, conveyor belts, vehicles, bolts, nuts, springs and screens, etc. |
Certificate | ISO, SGS, BV, etc. |
Production Technology | Hot Rolling, Cold Rolling |
Edge Processing | Edging, Trimming |
| STS | USA | UNS | CHINA | EURONORM | RUSSIA | SWEDISH | JAPANESE | |
| GRADE | AISI/ASTM | NO | GB | NO | NAME | GOST | SS | JIS |
| 430 | 430 | S43000 | 10Cr17 | 1.4016 | X8Cr17 | 12X17 | 2320 | SUS 430 |
| Grade | Standard | Chemical Composition(%) | |||||||
| C | Si | Mn | P | S | Cr | Ni | Mo | ||
| 430 | ASTM A240 | ≤0.12 | ≤1.00 | ≤1.00 | ≤0.040 | ≤0.030 | 16.00~18.00 | ≤0.75 | - |
| Grade | EN Grade | Tensile Test | Hardness Test | |||
| 0.2% Y.S(Mpa) | T.S(Mpa) | Elongation(%) | Hardness | HV | ||
| 430 | 1.4016 | 200~450 | 450~600 | 18~30 | Annealed | 150 |
