A709 steel coil is high-strength alloy steel coil that is widely used in construction, bridges, ships, automobiles and other fields. The chemical composition of A709 steel coil mainly includes carbon, silicon, manganese, phosphorus, sulfur, chromium, nickel and other elements. The carbon content is relatively high, generally between 0.22%-0.29%.
Product Name | A709/S355J0W Carbon Steel Coil |
Production Process | Hot Rolling, Cold Rolling |
Material Standards | AISI,ASTM,ASME,DIN,BS,EN,ISO,JIS,GOST,SAE etc. |
Width | 45mm-2200mm |
Length | Custom Size |
Thickness | Hot Rolling: 2.75mm-100mm |
Delivery Conditions | Rolling, Annealing, Quenching, Tempered or Standard |
Surface Process | Ordinary, Wire Drawing, Laminated Film |
Chemical Composition
A709 | 50W | 50 | 36 | |||||
Type A | Type B | Type C | ≤ 20 mm | 20-40 mm | 40-65 mm | 65-100 mm | ||
C | 0.19 | 0.20 | 0.15 | 0.23 | 0.25 | 0.25 | 0.25 | 0.27 |
Mn | 0.80-1.25 | 0.75-1.35 | 0.80-1.35 | 1.35 | - | 0.80-1.20 | 0.80-1.20 | 0.80-1.20 |
P.max | 0.04 | 0.04 | 0.04 | 0.04 | 0.04 | 0.04 | 0.04 | 0.04 |
S.max | 0.05 | 0.05 | 0.05 | 0.05 | 0.05 | 0.05 | 0.05 | 0.05 |
Si.max | 0.30-0.65 | 0.30-0.65 | 0.15-0.40 | - | 0.40 | 0.40 | 0.15-0.40 | 0.15-0.40 |
With..min | 0.25-0.40 | 0.20-0.40 | 0.20-0.50 | - | 0.20 | 0.20 | 0.20 | 0.20 |
Ni.max | 0.40 | 0.50 | 0.25-0.50 | - | - | - | - | - |
Cr | 0.40-0.65 | 0.40-0.70 | 0.30-0.50 | - | - | - | - | - |
V | 0.02-0.10 | 0.01-0.10 | 0.01-0.10 | - | - | - | - | - |
Mechanical Properties
A709 | Thickness mm | Yield Strength min | Tensile Strength min | Elongation % | |
200 mm | 50 mm | ||||
36 | ≤ 100 | 250 | 400-550 | 20 | 23 |
50 | ≤ 100 | 345 | 450 | 18 | 21 |
50S | - | 345-450 | 450 | - | - |
50W, HPS50W | ≤ 100 | 345 | 485 | 18 | 21 |
HPS70W | ≤ 100 | 485 | 585-760 | - | 19 |
100, 100W, HPS100W | ≤ 65 | 690 | 760-895 | - | 18 |
100, 100W | 65-100 | 620 | 690-895 | - | 16 |
Physical Performance
Physical Performance | Metric | Imperial |
Density | 7.80 g/cc | 0.282 lb/in³ |
