3003 Aluminum Coil

3003 aluminum coil is a commonly used product in the aluminum-manganese alloy series. This product has excellent anti-rust properties and is also called anti-rust aluminum coil with the addition of manganese alloy element. It is often used for processing parts and components that need good formability, high corrosion resistance and good weldability.

Product Details

3003 Aluminum Coil Description

3003 aluminum coil is the most widely used anti-rust aluminum so far. The strength of this alloy is slightly higher than industrial pure aluminum and it cannot be strengthened by heat treatment. Therefore, cold working methods are used to improve its mechanical properties. It has high plasticity in the annealed state, good plasticity in semi-cold work hardening, low plasticity in cold work hardening. It is mainly used for low-load parts that require high plasticity and good weldability and work in liquid or gas media, such as fuel tanks, gasoline or lubricating oil conduits, various liquid containers and other small-load parts made by deep drawing. 3003 aluminum coils are commonly used in ships, warships, vehicle materials, automobile and aircraft plate welding parts, pressure vessels that require strict fire protection.

Product parameters

Product Name

Aluminum coil

Standard

ASTM-B209. EN573-1, GB/T3880.1-2006,JIS H4000

Material

1100/1050/1060/1070/1200/1350
2014/2017A/2024/2A12/2219

3003/3004/3104/3005/3105
5005/5052/5082/8083/5182/5251/5454/5754
6061/6082/6063/6K61/6Z61
7072/7075
8011

Thickness

0.12mm-5mm or as customer requirements

Width

20mm-1500mm or as customer requirements

Length

Coil or As customer requirements

Surface treatment

Mill finish ,Color coated(PVDF& PE),Stucco Embossed ,Bright Polish,Anodizing,Mirror,Brush,Perforated,Tread plate ,Corrugated etc

Applications

Further making utensil
Solar reflective film
The appearance of the building
Interior decorating; ceilings, walls,etc
Furniture cabinets
Elevator decoraction
Signs, nameplate,bags making
Decorated inside and outside the car
Household appliances:refrigerators, microwave ovens, audio equipment,etc

MOQ

1 ton

Package

Water proof paper+wooden pallets or as requirements.

Delivery time

15-21 days after confirmed order

Chemical Composition

Alloy

Si

Fe

Cu

Mn

Mg

Cr

Zn

Ti

Others:

Each

Others:

Total

Al: Min.

1050

0.25

0.40

0.05

0.05

0.05

-

0.05

0.03

0.03

-

99.50

1060

0.25

0.35

0.05

0.03

0.03

-

0.05

0.03

0.03

-

99.60

1070

0.20

0.25

0.04

0.03

0.03

-

0.04

0.03

0.05

-

99.70

1100

0.95 Si Fee

0.05~0.20

0.05

-

-

0.1

-

0.05

0.15

99.0

2014

0.5~1.2

0.7

3.9~5.0

0.4~1.2

0.2~0.8

0.10

0.25

0.15

0.05

0.15

Allowance

2017

0.2~0.8

0.7

3.5~4.5

0.4~1.0

0.4~0.8

0.10

0.25

0.15

0.05

0.15

91.5 - 95.5

2024

0.50

0.50

3.8~4.9

0.3~0.9

1.2~1.8

0.10

0.25

0.15

0.05

0.15

Allowance

3003

0.60

0.70

0.05~0.20

1.0~1.5

-

-

0.10

-

0.05

0.15

Allowance

3A21

0.60

0.70

0.20

1.0-1.6

0.05

-

0.15

0.1-0.2

-

-

Allowance

3004

0.30

0.70

0.25

1.0~1.5

0.8~1.3

-

0.25

-

0.05

0.15

Allowance

3005

0.60

0.70

0.30

1.0~1.5

0.2~0.6

0.10

0.25

0.10

0.05

0.15

Allowance

3105

0.60

0.70

0.30

0.3~0.8

0.2~0.8

0.20

0.40

0.10

0.05

0.15

Allowance

5005

0.30

0.70

0.20

0.20

0.5~1.1

0.1

0.25

-

0.05

0.15

Allowance

5052

0.25

0.40

0.10

0.10

2.2~2.8

0.15~0.35

0.10

-

0.05

0.15

Allowance

5754

0.40

0.40

0.10

0.50

2.6~3.6

0.30

0.20

0.15

0.05

0.15

Allowance

5A05

0.50

0.50

0.10

0.3-0.6

4.8-5.5

-

0.20

-

0.05

0.05

Allowance

5083

0.40

0.40

0.10

0.4~1.0

4.0~4.9

0.05~0.25

0.25

0.15

0.05

0.15

Allowance

6061

0.40~0.8

0.70

0.15~0.4

0.15

0.8~1.2

0.04~0.35

0.25

0.15

0.05

0.15

Allowance

6082

0.70~1.3

0.50

0.10

0.4~1.0

0.6~1.2

0.25

0.20

0.10

0.05

0.15

Allowance

7075

0.40

0.50

1.2~2.0

0.30

2.1~2.9

0.18~0.28

5.1~6.1

0.20

0.05

0.15

Allowance



Mechanical Properties

Tensile Strength

 (MPa)

Test Stress

(MPa)

Hardness

HB

Elongation Rate

(%)

95-135

≥ 35

28

10



Physical Performance

Density

Melting Point

Thermal Expansion

Thermal Conductivity

Resistivity

2.73 Kg/m³

655 °C

23.1(10 -6/℃)

190 W/m.K

0.034× 10-6Ω.m



Annealing State

Brand

Annealing State

1xxx: 1050, 1050A, 1060, 1100

O, H12, H14, H16, H18, H22, H24, H26, H28, H111

3xxx: 3003, 3004, 3005, 3105

5xxx: 5005, 5052, 5754, 5083, 5086, 5182, 5049, 5251, 5454

O, H22, H24, H26, H28, H32, H34, H36, H38, H111

6xxx: 6061, 6082

T4, T6, T451, T651

2xxx: 2024

T3, T351, T4

7xxx: 7075

T6, T651
