C45 steel coil is a medium carbon high-quality steel with high strength and good mechanical properties, widely used in the manufacturing of high-strength components such as gears, shafts, piston pins, etc.
High strength: C45 steel has high strength and toughness, which makes it suitable for use in applications where high strength is required. Good machinability: C45 steel has good machinability, which means it can be easily machined into desired shapes and sizes. Weldability: C45 steel has good weldability, which means it can be easily welded using various welding techniques without experiencing significant degradation in its mechanical properties. Wear resistance: C45 steel has good wear resistance, which makes it suitable for use in applications where the material is subjected to abrasion and wear. Corrosion resistance: C45 steel is not a corrosion-resistant material, but it can be protected from corrosion by applying coatings or surface treatments. Versatility: C45 steel is versatile and can be used in a wide range of applications, such as in the manufacturing of home appliances, furniture, and structural components.
| Product Name | C45 Carbon Steel Coil Carbon Structural Steel |
|---|---|
| Thickness | Cold rolled:0.06mm-3.0mm; Hot rolled: 1.0mm-20mm |
| Width | 1500mm – 2500m or customized as required |
| Length | All Sizes Can be customized |
| Surface Finish | All Sizes Can be customized |
| Standard | ASTM, JIS, GB, AISI, DIN, BS, EN |
| Certifications | ISO 9001 BV SGS |
| Packing | Industry standard packaging or according to client’s requirement |
| Payment terms | T / T or L / C at sight |
| Trade Terms | EXW, FOB, CIF, CFR |
| Loading Port | TIANJIN, SHANGHAI, DALIAN QINGDAO, etc |
| Delivery time | Fast delievery in 7 days, up to order quantity |
| Quality | Mill Test Certificate supplied with the shipmenT / Third part inspection is acceptable |
| Packing Detail | Standard export package:Wooden pallet +paperboard +steel strip Customized requirements are accepted |
| Cutting Type | All Sizes Can be customzied |
| MOQ | 1 Ton |
| Capacity | 10, 000 ton per month |
| C45 Grade Worldwide Equivalents | ||||
|---|---|---|---|---|
| Country | USA | British | Japan | Australia |
| Standard | ASTM A29 | EN 10083-2 | JIS G4051 | AS 1442 |
| Grades | 1045 | C45/1.1191 | S45C | 1045 |
| Carbon Structural Steel AISI C45 Chemical Composition(%) | ||||||||
|---|---|---|---|---|---|---|---|---|
| Standard | Grade | C | Mn | P | S | Si | Ni | Cr |
| ASTM A29 | 1045 | 0.43-0.50 | 0.60-0.90 | 0.04 | 0.050 | |||
| EN 10083-2 | C45/1.1191 | 0.42-0.50 | 0.50-0.80 | 0.03 | 0.035 | 0.4 | 0.4 | 0.4 |
| JIS G4051 | S45C | 0.42-0.48 | 0.60-0.90 | 0.03 | 0.035 | 0.15-0.35 | ||
| Mechanical Properties in Quenched+Tempered Condition | |||||
|---|---|---|---|---|---|
| Diameter d (mm) | Thickness t (mm) | 0.2 % proof stress (N/mm2) | Tensile strength (N/mm2) | Elongation A5 (%) | Reduction Z (%) |
| <16 | <8 | min. 490 | 700-850 | min. 14 | min. 35 |
| <17-40 | <8<=20 | min. 430 | 650-800 | min. 16 | min. 40 |
| <41-100 | <20<=60 | min. 370 | 630-780 | min. 17 | min. 45 |
| Mechanical Properties in Normalized Condition | |||||
|---|---|---|---|---|---|
| Diameter d (mm) | Thickness t (mm) | 0.2 % proof stress (N/mm2) | Tensile strength (N/mm2) | Elongation A5 (%) | |
| <16 | <16 | min. 390 | min. 620 | min. 14 | |
| <17-100 | <16<=100 | min. 305 | min. 305 | min. 16 | |
| <101-250 | <100<250 | min. 275 | min. 560 | min. 16 | |
