301 Stainless Steel – An austenitic stainless steel alloy renowned for its high strength and commendable corrosion resistance. This grade is particularly adept at handling mildly corrosive environments while maintaining its integrity at ambient temperatures.
Type 301 is an austenitic stainless steel, alloyed with chromium and nickel, known for its versatility in both annealed and cold worked conditions. When annealed, it provides exceptional stretch formability, surpassing all other stainless steels. As it undergoes cold working, it transforms to exhibit the highest strength levels found within the 300 series stainless steels. Initially non-magnetic, 301 becomes magnetic after cold working, reflecting its transformative properties.
Although 301 stainless steel is corrosion-resistant across various environments, its anti-corrosive capabilities slightly trail behind those of the 304/304L stainless steel variants, primarily due to its vulnerability to carbide precipitation during the welding process. This particular characteristic sometimes necessitates opting for 304L, with its reduced carbon content, in welding applications to avoid such precipitation and maintain the integrity of the weld.
301 stainless steel is a widely used austenitic stainless steel known for its excellent corrosion resistance and high carbon content, enabling versatile cold working to achieve various tempers, including 1/4 hard, 1/2 hard, and full hard conditions. This adaptability makes it ideal for a multitude of applications requiring both formability and tensile strength.
The alloy exhibits remarkable ductility, especially in cold-worked conditions, making it well-suited for numerous welding techniques. It's easily formable and drawable, which, coupled with its high strength and outstanding corrosion resistance, renders it perfect for demanding sectors like aerospace, automotive, and rail.
The low carbon variant, 301L, offers enhanced ductility, ideal for applications needing extensive forming or welding. Overall, 301 stainless steel combines formidable strength with superior corrosion resistance, providing a reliable material solution for advanced engineering and manufacturing projects.
Product Name | Stainless Steel Coils | |||
Length | As required | |||
Width | 10mm-2000mm or as required | |||
Thickness | HR:2.5mm-14mm,CR:0.18mm-3mm or as required | |||
Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. | |||
Technique | Hot rolled / cold rolled | |||
Surface Treatment | 2B or according to customer requirement | |||
Thickness tolerance | ±0.01mm | |||
Material | 201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S 309S, 410, 410S,420, 430, 431, 440A,904L | |||
It is widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture, | ||||
MOQ | 1ton. We also can accept sample order. | |||
Shipment time | Within 5-20days after receiving deposit | |||
Export packing | Waterproof paper, and steel strip packed. Standard Export Seaworthy Package. Suit for all kinds of transport,or as required | |||
| STS | USA | UNS | CHINA | EURONORM | RUSSIA | SWEDISH | JAPANESE | |
| GRADE | AISI/ASTM | NO | GB | NO | NAME | GOST | SS | JIS |
| 301 | 301 | S30100 | 0Cr17Ni7 | 1.4310 | X5CrNi17-7 | 03Х17Н7 | X12CrNi17-7 | SUS 301 |
| Grade | Standard | Chemical Composition(%) | |||||||
| C | Si | Mn | P | S | Cr | Ni | N | ||
| 301 | ASTM A240 | ≤0.15 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.030 | 16.00~18.00 | 6.00~8.00 | ≤0.10 |
| Grade | Conditions | Tensile Test | Hardness Test | ||
| 0.2% Y.S(Mpa) | T.S(Mpa) | Elongation(%)≥ | HRB | ||
| 301 | Annealed | ≥205 | ≥515 | 40 | 95 |
| 1/16 Hard | ≥310 | ≥620 | 40 | - | |
| 1/8 Hard | ≥380 | ≥690 | 40 | - | |
| 1/4 Hard | ≥515 | ≥860 | 25 | - | |
| 1/2 Hard | ≥760 | ≥1035 | 15 (<0.015") 18 (≥0.015") | - | |
| 3/4 Hard | ≥930 | ≥1205 | 10 (<0.015") 12 (≥0.015") | - | |
| Full Hard | ≥965 | ≥1275 | 8 (<0.015") 9 (≥0.015") | - | |
| Super Full Hard | ≥1790 | ≥1860 | 0 | - | |
Grade 301 stainless steel is utilized extensively in a variety of industrial and commercial applications, where its strength and durability are highly valued. Key uses include:
Rail Car Components: Ideal for structural parts due to its high strength and resistance to corrosion, ensuring longevity and reliability in demanding conditions.
Aircraft Structures: Used in airframe sections where its combination of strength and lightweight properties are crucial.
Trailer Components: Employs its robustness in highway trailers, contributing to structural integrity and longevity.
Automotive Parts: Including wheel covers and wiper blade clips, where its aesthetic appeal and corrosion resistance are beneficial.
Appliance Parts: Utilized in stove element clips and toaster springs, showcasing its resistance to heat and mechanical stress.
Building Materials: Applied in screen frames and curtain walls, offering both structural strength and a polished appearance.
These diverse applications underscore 301 stainless steel's adaptability and performance in environments requiring durability, precision, and aesthetic quality.
