409 stainless steel is a ferritic steel with good mechanical properties and high temperature corrosion resistance. It contains 11% chromium, which is the minimum amount required to form the passive surface film that makes stainless steel corrosion-resistant.
The chemical composition of 409 stainless steel sets it apart from other types of stainless steel. It is mainly composed of iron, with large amounts of chromium and small amounts of carbon, manganese, silicon and nitrogen. Iron is the primary element of 409 stainless steel, providing its strength and stability. Chromium gives the alloy corrosion resistance and helps form a protective oxide layer on the surface. Carbon helps increase the material's hardness and wear resistance. Manganese acts as a stabilizer to prevent excessive grain growth during heat treatment. Silicon enhances oxidation resistance while minimizing scaling at high temperatures. Nitrogen improves mechanical properties such as tensile strength and yield strength. This unique combination of elements gives 409 stainless steel excellent thermal expansion capabilities, making it suitable for high-temperature applications without compromising its structural integrity or dimensional stability. Its chemical composition also provides good solderability, thus simplifying the manufacturing process.
Grade | 201/202/301/303/304/304L/316/316L/321/310S/401/409/410/420J1/420J2/430/439/443/444/2205/2507 |
Surface Finish | 2B, BA, NO.1, NO.4, 8K, HL, Embossing, Satin, Mirror, ect |
Standard | JIS/SUS/GB/DIN/ASTM/AISI/EN |
Technique | Cold Rolled; Hot Rolled |
Thickness | 0.3-4mm cold rolled; 3-16mm hot rolled; Customized according to customer requirements |
Width | 10-600mm |
Application | Interior/Exterior decoration; Architectur; Evevator; Kitchen; Ceiling; Cabinet; Advertising nameplate; Roof structure; Shipbuilding |
Lead Time | 7-15 working days after the receipt of 30% deposit |
Payment Terms | 30% TT for deposit,70% TT /70% LC at sight balance before shipment |
Price Terms | FOB, EXW, CIF, CFR |
Packing | Wooden Pallet or according to customer's requirements |
Chemical Composition
C | Si | Mn | Cr | Ni | S | P |
≤ 0.08 | ≤1.0 | ≤1.0 | 10.5～11.75 | ≤ 0.5 | ≤ 0.045 | ≤ 0.045 |
Mechanical Properties
Tensile Strength Kb (MPa) | Yield Strength σ0.2 (MPa) | Elongation D5 (%) | Hardness |
≥360 | ≥175 | ≥25 | ≤ 162HBW |
Physical Performance
Density(g/cm³) | Modulus of Elasticity(Gpa) | Coefficient of Thermal Expansion(10-6/°C) | Coefficient of Thermal Conductivity(W/m*K) | Resistivity(NΩ.m) |
7.80 | 200 | 11.0 | 25.8 | 600 |
